Trane S8B1A040M3PSC Installation, Operation And Maintenance

S8XB-SVX001-1B-EN
21
Furnace Airflow (CFM) Vs. External Static Pressure (in. W.C.)
Model
Tap
Static 0.1 0.3 0.5 0.7 0.9
S8*1C080M5PSC
S8X2C080M5PSC
1
SCFM / Watts 728 / 44 358 / 49
2
SCFM / Watts 809 / 53 540 / 63 271 / 74
3
SCFM / Watts 1440 / 185 1273 / 201 1105 / 218 938 / 234 770 / 250
4
SCFM / Watts 1536 / 220 1385 / 238 1233 / 257 1081 / 275 929 / 293
5
SCFM / Watts 1689 / 278 1552 / 299 1414 / 320 1277 / 342 1140 / 363
6
SCFM / Watts 1792 / 326 1661 / 348 1530 / 371 1400 / 394 1269 / 417
7
SCFM / Watts 1899 / 373 1771 / 397 1643 / 422 1515 / 446 1387 / 471
8
SCFM / Watts 2094 / 500 1985 / 527 1875 / 554 1766 / 582 1656 / 609
9
SCFM / Watts 2533 / 931 2414 / 932 2295 / 933 2176 / 933 2058 / 934
Furnace Airflow (CFM) Vs. External Static Pressure (in. W.C.)
Model
Tap
Static 0.1 0.3 0.5 0.7 0.9
S8*1C100M5PSCB
S8X2C100M5PSC
1
SCFM / Watts 821 / 55 442 / 55
2
SCFM / Watts 1359 / 163 1195 / 180 1031 / 198 868 / 215 704 / 233
3
SCFM / Watts 1602 / 246 1461 / 268 1321 / 290 1180 / 312 1040 / 334
4
SCFM / Watts 1807 / 336 1678 / 362 1550 / 388 1421 / 414 1292 / 440
5
SCFM / Watts 1827 / 345 1700 / 371 1572 / 398 1444 / 425 1317 / 451
6
SCFM / Watts 1925 / 395 1800 / 423 1675 / 451 1550 / 479 1425 / 508
7
SCFM / Watts 2102 / 503 1985 / 534 1869 / 566 1752 / 597 1635 / 628
8
SCFM / Watts 2222 / 602 2115 / 635 2008 / 667 1901 / 700 1794 / 732
9
SCFM / Watts 2458 / 896 2351 / 913 2245 / 930 2138 / 947 2032 / 964
Furnace Airflow (CFM) Vs. External Static Pressure (in. W.C.)
Model
Tap
Static 0.1 0.3 0.5 0.7 0.9
S8*1D120M5PSC
S8X2D120M5PSC
1
SCFM / Watts 1469 / 184 912 / 126 355 / 68
2
SCFM / Watts 1429 / 175 1165 / 171 900 / 168 636 / 164 371 / 160
3
SCFM / Watts 1567 / 215 1401 / 232 1235 / 248 1069 / 264 903 / 280
4
SCFM / Watts 1858 / 334 1731 / 361 1605 / 388 1478 / 415 1351 / 441
5
SCFM / Watts 2004 / 418 1890 / 447 1776 / 476 1662 / 505 1548 / 534
6
SCFM / Watts 2110 / 488 2004 / 518 1898 / 549 1792 / 580 1686 / 611
7
SCFM / Watts 2245 / 596 2148 / 629 2052 / 662 1956 / 695 1860 / 729
8
SCFM / Watts 2440 / 765 2345 / 794 2250 / 824 2155 / 854 2060 / 884
9
SCFM / Watts 2536 / 882 2431 / 904 2325 / 927 2220 / 949 2114 / 972
AAiirrffllooww TTaabblleess
