S8XB-SVX001-1C-EN
MODEL
S8*1C080M5PSCA/C
(a)
S8*1C100M5PSCB/C
(a)
S8*1D120M5PSCA/C
(a)
Type Upflow / Horizontal / Downflow Upflow / Horizontal / Downflow Upflow / Horizontal / Downflow
RATINGS
(b)
Input BTUH 80,000 100,000 120,000
Capacity BTUH (ICS)
(c)
64,700 80,700 98,000
Temp. Rise (Min. - Max.) °F
30 - 60 30 - 60 35 - 65
AFUE - Rating
(c)
80 80 80
Return Air Temp. (Min. - Max.) °F
55°F - 80°F 55°F - 80°F 55°F - 80°F
BLOWER DRIVE DIRECT DIRECT DIRECT
Diameter - Width (in.)
11 X 11 11 X 11 11 X 11
No. Used 1 1 1
Speeds (No.)
(d)
CTM - 9 CTM - 9 CTM - 9
CFM vs. in. w.g.
See Fan Performance Table See Fan Performance Table See Fan Performance Table
Motor HP 1
3/4
1
R.P.M. 1050 1050 1050
Volts / Ph / Hz 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
FLA 10.9 10.9 10.9
COMBUSTION FAN - Type
PSC PSC PSC
Drive - No. Speeds
Direct - 1 Direct - 1 Direct - 1
Motor RPM
3300/2971 3300/2680 3300/3025
Volts/Ph/Hz 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
FLA
0.30/0.43 0.33/0.58 0.33/0.57
Inducer Orifice 1.80 2.50 2.15
FILTER - Furnished? No No No
Type Recommended High Velocity High Velocity High Velocity
Hi Vel. (No.-Size-Thk.)
1 - 20 X 25 - 1 in. 1 - 20 X 25 - 1 in. 1 - 24 X 25 - 1 in.
VENT PIPE DIAMETER - Min.
(in.)
4 Round 4 Round 4 Round
HEAT EXCHANGER - Type
Aluminized Steel Aluminized Steel Aluminized Steel
Gauge (Fired)
20 - 19 20 - 19 20 - 19
ORIFICES - Main
Nat. Gas Qty. - Drill Size
4 - 45 5 - 45 6 - 45
L.P. Gas Qty. - Drill Size
4 - 56 5 - 56 6 - 56
GAS VALVE
Redundant - Single Stage Redundant - Single Stage Redundant - Single Stage
PILOT SAFETY DEVICE - Type 120 V SiNi Igniter 120 V SiNi Igniter 120 V SiNi Igniter
BURNERS - QTY
4 5 6
POWER CONN. - V/Ph/HZ
(e)
120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
Ampacity (Amps)
14.1/14.2 14.1/14.4 14.1/14.4
Max. Overcurrent Protection
(Amps)
15 15 15
PIPE CONN. SIZE (IN.)
1/2 1/2 1/2
