18-CE16D1-1B-EN
29
Furnace in Horizontal Right with “A” Coil
1. Bend furnace side flanges down.
2. Support the furnace and coil independently.
Note: Flat or dedicated horizontal coils may require flanges to be bent
upward.
Downflow Furnace with Coil
1. Bend furnace side flanges down.
2. Support the furnace and coil independently.
FFuurrnnaaccee GGeenneerraall IInnssttaallllaattiioonn
