Trane S8X2C080M5PSC Installation, Operation And Maintenance

10
S8XB-SVX001-1B-EN
MODEL
S8*1B080M4
PSCA
(a)
S8*1B080M4
PSCB
(a)
S8*1C080M5
PSC
(a)
S8*1C100M5
PSCB
(a)
S8*1D120M5
PSC
(a)
Type
Upflow / Horizontal /
Downflow
Upflow / Horizontal /
Downflow
Upflow / Horizontal /
Downflow
Upflow / Horizontal /
Downflow
Upflow / Horizontal /
Downflow
RATINGS
(b)
Input BTUH 80,000 80,000 80,000 100,000 120,000
Capacity BTUH (ICS)
(c)
65,100 65,100 64,700 80,700 98,000
Temp. Rise (Min. -
Max.) °F
30 - 60 30 - 60 30 - 60 30 - 60 35 - 65
AFUE - Rating
(c)
80 80 80 80 80
Return Air Temp. (Min.
- Max.) °F
55°F - 80°F 55°F - 80°F 55°F - 80°F 55°F - 80°F 55°F - 80°F
BLOWER DRIVE DIRECT DIRECT DIRECT DIRECT DIRECT
Diameter - Width (in.)
11 X 8 11 X 8 11 X 11 11 X 11 11 X 11
No. Used 1 1 1 1 1
Speeds (No.)
(d)
CTM - 9 CTM - 9 CTM - 9 CTM - 9 CTM - 9
CFM vs. in. w.g.
See Fan Performance
Table
See Fan Performance
Table
See Fan Performance
Table
See Fan Performance
Table
See Fan Performance
Table
Motor HP
3/4 3/4
1
3/4
1
R.P.M. 1050 1050 1050 1050 1050
Volts / Ph / Hz 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
FLA 9.2 9.2 10.9 10.9 10.9
COMBUSTION FAN -
Type
PSC SP PSC PSC PSC
Drive - No. Speeds
Direct - 1 Direct - 1 Direct - 1 Direct - 1 Direct - 1
Motor RPM 3300 3300 3300 3300 3300
Volts/Ph/Hz 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
FLA 0.29 1.4 0.30 0.33 0.33
Inducer Orifice 2.15 2.15 1.80 2.50 2.15
FILTER - Furnished? No No No No No
Type Recommended High Velocity High Velocity High Velocity High Velocity High Velocity
Hi Vel. (No.-Size-Thk.)
1 - 16 X 25 - 1 in. 1 - 16 X 25 - 1 in. 1 - 20 X 25 - 1 in. 1 - 20 X 25 - 1 in. 1 - 24 X 25 - 1 in.
VENT PIPE
DIAMETER - Min.
(in.)
4 Round 4 Round 4 Round 4 Round 4 Round
HEAT EXCHANGER -
Type
Aluminized Steel Aluminized Steel Aluminized Steel Aluminized Steel Aluminized Steel
Gauge (Fired)
20 - 19 20 - 19 20 - 19 20 - 19 20 - 19
ORIFICES - Main
Nat. Gas Qty. - Drill
Size
4 - 45 4 - 45 4 - 45 5 - 45 6 - 45
L.P. Gas Qty. - Drill Size
4 - 56 4 - 56 4 - 56 5 - 56 6 - 56
GAS VALVE
Redundant - Single
Stage
Redundant - Single
Stage
Redundant - Single
Stage
Redundant - Single
Stage
Redundant - Single
Stage
PILOT SAFETY
DEVICE - Type
120 V SiNi Igniter 120 V SiNi Igniter 120 V SiNi Igniter 120 V SiNi Igniter 120 V SiNi Igniter
BURNERS - QTY
4 4 4 5 6
POWER CONN. - V/
Ph/HZ
(e)
120 / 1 / 60 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60 120 / 1 / 60
Ampacity (Amps)
12.0 13.1 14.1 14.1 14.1
Max. Overcurrent
Protection (Amps)
15 15 15 15 15
PIPE CONN. SIZE
(IN.)
1/2 1/2 1/2 1/2 1/2
PPrroodduucctt SSppeecciiffiiccaattiioonn
