Trane S8X2D120M5PSAB User Manual

18-CE04D1-1D-EN
23
Table 6. High Altitude Kit
Furnace Models Kit Model No. PS1-LOW SET PT PS2-HIGH SET PT
S8X1A026M2P* BAYSWT20AHALTAA NA
-0.25" +/- 0.05" WC
S8X1A040M3P* BAYSWT21AHALTAA NA
-0.47" +/- 0.05" WC
S8X1B040M2P* BAYSWT21AHALTAA NA
-0.47" +/- 0.05" WC
S8X1B060M3P* BAYSWT15AHALTAA NA
-0.60" +/- 0.05" WC
S8X1B060M4P* BAYSWT15AHALTAA NA
-0.60" +/- 0.05" WC
S8X1B080M4P* BAYSWT15AHALTAA NA
-0.60" +/- 0.05" WC
S8X1C080M5P* BAYSWT14AHALTAB NA
-0.50" +/- 0.05" WC
S8X1C100M5P* BAYSWT14AHALTAB NA
-0.50" +/- 0.05" WC
S8X1D120M5P* BAYSWT14AHALTAB NA
-0.50" +/- 0.05" WC
S8X2A040M3P* BAYSWT22AHALTAA
-0.25" +/- 0.05" WC -0.47" +/- 0.05" WC
S8X2B060M3PSAAA BAYSWT17AHALTAA
-0.30" +/- 0.05" WC -0.60" +/- 0.05" WC
S8X2B060M4PSAAA BAYSWT17AHALTAA
-0.30" +/- 0.05" WC -0.60" +/- 0.05" WC
S8X2B060M3PSAAB & later BAYSWT23AHALTAA
-0.40" +/- 0.05" WC -0.70" +/- 0.05" WC
S8X2B060M3PTAAA & later BAYSWT23AHALTAA
-0.40" +/- 0.05" WC -0.70" +/- 0.05" WC
S8X2B060M4PSAAB & later BAYSWT23AHALTAA
-0.40" +/- 0.05" WC -0.70" +/- 0.05" WC
S8X2B060M4PTAAA & later BAYSWT23AHALTAA
-0.40" +/- 0.05" WC -0.70" +/- 0.05" WC
S8X2B080M4P* BAYSWT18AHALTAA
-0.37" +/- 0.05" WC -0.60" +/- 0.05" WC
S8X2C080M5P* BAYSWT16AHALTAB
-0.25" +/- 0.05" WC -0.50" +/- 0.05" WC
S8X2C100M5P* BAYSWT19AHALTAA
-0.37" +/- 0.05" WC -0.50" +/- 0.05" WC
S8X2D120M5P* BAYSWT24AHALTAA
0.45" +/ 0.05"WC -0.50" +/- 0.05" WC
FFuurrnnaaccee GGeenneerraall IInnssttaallllaattiioonn
