Programming And Operation
O
tion Function O
tion Value Default Descri
tion
1 Morning warm-up 0 = Disabled
1 = Enabled
0 When enabled, Heat is turned on if the Zone
temperature is 2 degrees below the heat set point
temperature when the program switches from
unoccupied to occupied. The heat will terminate after 60
minutes regardless if the set point has been reached.
2 Economizer minimum
position override
0 = Disabled
1 = Enabled
1 When enabled, the minimum position of the economizer
damper is overridden during the unoccupied period.
3 Temperature Scale 0 = Fahrenheit
1 = Centi
rade
0 Displays the temperature in the selected format.
4 Supply Air Tempering 0 = Disabled
=
0 When enabled, sends the tempering signal to the UCP.
5 Time Clock 0 = 12 hour
1 = 24 hour
0 Sets Clock to 12 hour format with AM and PM or 24 hour
military time.
6 Smart Fan 0 = Disabled
1 = Enabled
1 When enabled, the supply fan operates in the AUTO
mode during unoccupied periods regardless of FAN
setting.
7 Intelligent
Temperature
Recovery
0 = Disabled
1 = Enabled
0 When enabled, offsets the set point temperature and
starts the system before the scheduled occupied period
to efficiently reach the occupied temperature set point.
The time is calculated based on a recovery rate of 6
degrees per hour. If option 19 is set for HP, this option is
disabled during EMERgency heat operation.
8 Programmable
Days/Week
0 = 7 days (M, T, W, T, F,
S, S)
1 = 3 days (M-F, S, S)
2 = 2 days (M-F, S-S)
-
0 0 allows all 7 days to be individually programmed. 1
allows Mon - Fri, Sat & Sun to be programmed
separately. 2 allows Mon - Fri and Sat - Sun to be
programmed the same. 3 uses the same program for
9 Programmable
Periods/Day
2, 3, 4 4 If 2 is selected, only Day and Nite periods can be
programmed. If 3 is selected, Morn, Day, and Nite can
be programmed. If 4 is selected, Morn, Day, Eve, and
Nite can be pro
rammed.
10 Programmable Fan
Operation
0 = Disallowed
1 = Allowed
0 If allowed, Supply Fan operation can be programmed for
On or Auto operation for each programmed period.
11 Remote Sensor
Installed
0 = No
1 = Yes
0 Determines which source will supply the Room
Temperature input for display.
12 Check Filter Interval 0 = Disabled
3000 to 50 in 50 hour
increments
350 Adjustable in 50 hour increments. The CHECK FILTER
icon will flash when the accumulated run time is greater
than the interval setting.
13 Display Zone
Temperature
0 = No
1 = Yes
1 If ZSM is in a Normal Run State or in Temporary
Override, the zone temperature will be displayed.
14 Keypad Lockout
Enabled
0 = Disabled
1 = Enabled
1 When Enabled, Keypad can be locked out.
15 Default Temporary
1, 2, 3, 4, 5 3 Sets the default override time in hours.
16 Buzzer Options 0 = Key Press Only
1 = Key Press and Check
Filter
2 = Key Press, Check
Filter, and System Failure
1 Buzzer will sound for a 1/2 sec for every minute if option
is set for 1 or 2.
17 Zone Temperature
Calibration
Zone Tempersture
Displayed
0 offset This allows for field calibration in 0.1 degree increments
of either the internal sensor on the ZSM or the remote
sensor if used.
18 Baud Rate 0 = 1024 baud
1 = 1200 baud
1 Set to Zero for 3 - 25 Ton Voyager Units built before Jan.
1, 1996 that have the original UCP.
19 CV or HP Operation 0 = CV
1 = HP
0 This sets the operation MODE for the ZSM. If HP is
selected, EMERgency heat is available.
20 Default Cooling Set
Point
45 to 98 74 If no set point has been programmed or the program is
lost, the value set here becomes the operation set point.
21 Default Heating Set
Point
43 to 96 68 If no set point has been programmed or the program is
lost, the value set here becomes the operation set point.
22 Minimum Cooling Set
Point
45 to 98 45 Sets the minimum programmable cooling temperature
set point.
23 Maximum Heating Set
Point
43 to 96 96 Sets the maximum programmable heating temperature
set point.
To Next Page
