BAS-SVN032B-EN
13
Table 6. TR170 VFD Drive Parameters (continued)
Parameter Number Parameter Description CGAM Setting Units
1-23 Motor Frequency
(Motor Specific)
Hz
1-24 Motor Current
(Motor Specific)
A
1-25 Motor Nominal Speed (Motor Specific) RPM
1-71 Start Delay 3 s
1-72 Start Function DC Hold (0) —
1-73 Flying Start Default Value —
1-82 Min Speed for Function at Stop [Hz]
0.1 Hz
1-90 Motor Thermal Protection ETR Trip 1 (4) —
2-00 DC Hold/Motor Preheat Current Default Value %
2-02 DC Braking Time Default Value s
2-10 Brake Function Off (0) —
3-03 Maximum Reference 50/60 —
3-16
Reference 2 Source No function (0)
—
3-17
Reference 3 Source No function (0)
—
3-41 Ramp 1 Ramp Up Time 5 s
3-42 Ramp 1 Ramp Down Time 20 s
4-10 Motor Speed Direction Clockwise (0) —
4-12 Motor Speed Low Limit [Hz] 5/6 Hz
4-14 Motor Speed High Limit [Hz] 50/60 Hz
4-18 Current Limit
If p122 = 460V then 115 Else 110
%
5-12 Terminal 27 Digital Input No operation (0) —
5-40 Function Relay Alarm (9) —
6-10 Terminal 53 Low Voltage 1 V
6-14 Terminal 53 Low Ref./Feedb. Value 5/6 —
6-15
Terminal 53 High Ref./Feedb. Value 50/60 —
14-01 Switching Frequency 5 kHz
14-12 Function at Mains Imbalance De-rate (3) —
14-20 Reset Mode Auto Reset x10 (10) —
14-21 Automatic Restart Time 30 s
14-50
RFI Filter Off (0)
—
Note: *60 or 50Hz for Pueblo Production, 50Hz for Charmes production. Otherwise, set for maximum speed rating of motor/fan.
Please refer to BAS-SVP16*-EN (TR150 and TR170 Programming Guide), or the most recent
version, for complete programming information.
IInnssttaalllliinngg TTRR117700 VVFFDD aanndd CCoommppoonneennttss
