BAS-SVN032B-EN
19
Table 9. TR170 VFD drive parameters CGAM (continued)
Parameter Number Parameter Description CGAM Setting Units
14-50 RFI Filter Off (0) —
Note: *60 or 50Hz for Pueblo Production, 50Hz for Charmes production. Otherwise, set for maximum speed rating of motor/fan.
Copying Parameters to Multiple Drives
If you are installing multiple drives, the drive LCP (local control panel) can be used to copy
parameters from one drive to another. This method can save time and reduce errors.
UUppllooaaddiinngg DDaattaa ttoo tthhee LLCCPP
1. Go to 0-50 LCP copy.
2. Press OOKK.
3. Select AAllll ffrroomm LLCCPP.
4. Press OOKK.
A progress bar shows the uploading process
5. Press HHaanndd oonn to return to normal operation.
Remove the LCP from the configured drive and install it on the unconfigured drive.
DDoowwnnllooaaddiinngg DDaattaa ffrroomm tthhee LLCCPP
1. Go to 0-50 LCP copy
2. Press OOKK
3. Select AAllll ffrroomm LLCCPP
4. Press OOKK.
A progress bar shows the uploading process
5. Press HHaanndd oonn to return to normal operation.
IInnssttaalllliinngg TTRR117700 VVFFDD aanndd CCoommppoonneennttss
