10 CNT-PRC003-EN
Figure 6. Tracer VV551 dimensions
7.5 in. (19.2 cm)
6.5 in. (16.7 cm)
6.5 in. (16.7 cm)
7.5 in. (19.2 cm)
5.5 in. (14.0 cm)
Cover off
Cover on
