8
SSC-PRC008-EN
General Data
General Data MCX 50Hz: High Efficiency Models
UNIT MODELS MCX530GB5 MCX536GB5 MCX042GB5
POWER CONNECTION V/ph/Hz 220-240/1/50 220-240/1/50 220-240/1/50
MCA
1
A 1.53 1.62 1.62
SYSTEM DATA
Refrigerant Connection Type Flare Brazed Brazed
Suction Line OD in (mm) 3/4 (19) 3/4 (19) 7/8 (22.2)
Liquid line OD in (mm) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5)
COIL
Face Area sq ft (m
2
) 3.39 (0.32) 4.17 (0.39) 4.78 (0.44)
Tube Size OD in (mm) 7.0 mm 3/8 (9.5) 3/8 (9.5)
Tube Type Inner Grooved Inner Grooved Inner Grooved
Rows 5 4 4
Fin Type Slit/Coated Slit/Coated Slit/Coated
Fins per inch 18 17 18
Refrigerant Flow Control Capillary Tube Capillary Tube Capillary Tube
Drain Connection Size in (mm) 3/4 (19) 3/4 (19) 3/4 (19)
ELECTRIC HEATER DATA
Heater Rating kW - - -
Heater RLA - - -
FAN
Fan Type Centrifugal Centrifugal Centrifugal
No. used 4 4 4
Diameter in (mm) 6 (152) 6 (152) 6 (152)
Width in (mm) 7 (178) 9 (229) 9 (229)
Drive Type Direct Direct Direct
MOTOR
Motor Type Permanent Split Capacitor
No. of Motor 2 2 2
Motor Power hp (kW) 1/10 (0.056) 1/8 (0.076) 1/8 (0.076)
No. of Speed 4 4 4
Motor Speed rpm 1400/1200/1050/850 1450/1250/1000/800 1450/1250/1000/800
V/ph/Hz 220/1/50 220/1/50 220/1/50
RLA/LRA 0.68 / 1.18 0.72 / 1.23 0.72 / 1.23
FILTER
Type Polypropylene
No. used 4 6 6
No. used per size (WxLxD) in 2-8.15 x 9.84 x 0.66 4-8.15 x 9.84 x 0.66 4-8.15 x 9.84 x 0.66
2-8.15 x 17.3 x 0.66 2-8.15 x 17.3 x 0.66 2-8.15 x 17.3 x 0.66
(mm) 2-(207 x 250 x 16.8) 4-(207 x 250 x 16.8) 4-(207 x 250 x 16.8)
2-(207 x 440 x 16.8) 2-(207 x 440 x 16.8) 2-(207 x 440 x 16.8)
DIMENSION (HxWxD)
Crated (Shipping) in 27.2 x 64.6 x 11.0 27.2 x 84.1 x 11.0 27.2 x 84.1 x 11.0
(mm) (692 x 1,641 x 278) (692 x 2,137 x 278) (692 x 2,137 x 278)
Uncrated (Net) in 24.7 x 61.9 x 9.2 24.7 x 81.7 x 9.2 24.7 x 81.7 x 9.2
(mm) (627 x 1,574 x 234) (627 x 2,074 x 234) (627 x 2,074 x 234)
WEIGHT
Crated (Shipping)
Without electric heater lb (kg) 118 (53) 171 (77) 173 (78)
With electric heater lb (kg) - - -
Uncrated (Net)
Without electric heater lb (kg) 107 (48) 153 (69) 155 (70)
With electric heater lb (kg) - - -
1
MCA - Minimum Circuit Ampacity; calculated as follow : 125% of fan motor R.L Amps.
