SSC-PRC008-EN
7
General Data MCX 50Hz : High Efficiency Models
UNIT MODELS MCX512GB5 MCX518GB5 MCX524GB5
POWER CONNECTION V/ph/Hz 220-240/1/50 220-240/1/50 220-240/1/50
MCA
1
A 0.50 0.84 0.84
SYSTEM DATA
Refrigerant Connection Type Flare Flare Flare
Suction Line OD in (mm) 5/8 (15.9) 5/8 (15.9) 5/8 (15.9)
Liquid line OD in (mm) 3/8 (9.5) 3/8 (9.5) 3/8 (9.5)
COIL
Face Area sq ft (m
2
) 2.03 (0.19) 2.71 (0.25) 2.71 (0.25)
Tube Size OD in (mm) 7.0 mm 7.0 mm 7.0 mm
Tube Type Inner Grooved Inner Grooved Inner Grooved
Rows 3 3 5
Fin Type Slit/Coated Slit/Coated Slit/Coated
Fins per inch 18 18 18
Refrigerant Flow Control Capillary Tube Capillary Tube Capillary Tube
Drain Connection Size in (mm) 3/4 (19) 3/4 (19) 3/4 (19)
ELECTRIC HEATER DATA
Heater Rating kW - - -
Heater RLA A - - -
FAN
Fan Type Centrifugal Centrifugal Centrifugal
No. used 2 2 2
Diameter in (mm) 6 (152) 6 (152) 6 (152)
Width in (mm) 7 (178) 9 (229) 9 (229)
Drive Type Direct Direct Direct
MOTOR
Motor Type Permanent Split Capacitor
No. of Motor 1 1 1
Motor Power hp (kW) 1/20 (0.031) 1/10 (0.050) 1/10 (0.050)
No. of Speed 4 4 4
Motor Speed rpm 1150/950/800/650 1400/1200/ 1000/800 1400/1200/1000/800
V/ph/Hz 220/1/50 220/1/50 220/1/50
RLA/LRA 0.40 / 0.54 0.67 / 1.07 0.67 / 1.07
FILTER
Type Polypropylene
No. used 2 3 3
No. used per size (WxLxD) in 2-8.15 x 17.3 x 0.66 1-8.15 x 9.84 x 0.66 1-8.15 x 9.84 x 0.66
- 2-8.15 x 17.3 x 0.66 2-8.15 x 17.3 x 0.66
(mm) 2-(207 x 440 x 16.8) 1-(207 x 250 x 16.8) 1-(207 x 250 x 16.8)
- 2-(207 x 440 x 16.8) 2-(207 x 440 x 16.8)
DIMENSION (HxWxD)
Crated (Shipping) in 27.2 x 45.0 x 11.0 27.2 x 54.8 x 11.0 27.2 x 54.8 x 11.0
(mm) (692 x 1,143 x 278) (692 x 1,391 x 278) (692 x 1,391 x 278)
Uncrated (Net) in 24.7 x 42.3 x 9.2 24.7 x 51.1 x 9.2 24.7 x 51.1 x 9.2
(mm) (627 x 1,074 x 234) (627 x 1,324 x 234) (627 x 1,324 x 234)
WEIGHT
Crated (Shipping)
Without electric heater lb (kg) 73 (33) 87 (39) 93 (42)
With electric heater lb (kg) - - -
Uncrated (Net)
Without electric heater lb (kg) 67 (30) 75 (34) 82 (37)
With electric heater lb (kg) - - -
1
MCA - Minimum Circuit Ampacity; calculated as follow : 125% of fan motor R.L Amps.
