Hydraulic module control
25RLC-SVU02F-E4
Hydraulic module option
Permanent display
Access to this mask using the
Esc
key from any mask. The program will
return automatically into it after 5 min.
1 = Application name and version number
2 = Current date and time
3 = Ambient Air temperature
4 = Unit status:
"Pump 1 Running" Pump 1 is running
"Pump 2 Running" Pump 2 is running
"No Pump Request" No pump request sent by the UCM-CLD
"Pump 1 OVD" Manual Override on pump 1
"Pump 2 OVD" Manual Override on pump 2
"System OFF" System is OFF
"WFP Active" Winter Freeze Protection by pump is active
"Alarm" An Alarm is present
Access to sub-menus
Access to this mask using the
Prg
key. The sub-menu will be selected using
the
Up
and
Down
keys and selected using the
Enter
button.
1 = Data display menu
2 = Settings menu
3 = Clock menu
4 = Unit configuration menu
