Trane UCM-CLD - Hydraulic Module Data Display Menu

Hydraulic module control
RLC-SVU02F-E426
Data display menu
The following mask will be accessed using the Up and Down keys
Analog Inputs
1 = Customer return water temperature
2 = Ambient air temperature
Digital Inputs
1 = Pump 1 (Failed, Normal)
2 = Pump 2 (Failed, Normal)
3 = Water Flow (No, Yes)
4 = System Validation (No, Yes)
5 = Pump request (No,Yes)
Digital Outputs
1 = Pump 1 Output (No, Yes)
2 = Pump 2 Output (No, Yes)
3 = Heaters Output (No, Yes)
4 = Flow Switch Output (No,Yes)
5 = Alarm Output (No, Yes)
Counters
1 = Pump 1 Running hours
2 = Pump 2 Running hours
Pump 1 : 000000 hrs
Pump 2 : 000000 hrs
Pump 1 : Yes Pump 2 : No
Heaters : No
FS_Out : Yes
Alarm : No
5
Pump 1 Status:
Pump 2 Status:
Water flow:
Syst: Yes Pump In: Yes
Normal
Normal
Yes
5
Return Wat T
Outside Air T
