Trane UCM-CLD - Heat Recovery Digital Inputs; Heat Recovery Digital Outputs; Heat Recovery Analog Outputs

Heat Recovery Application
37RLC-SVU02F-E4
Digital Inputs
1 = Circuit 1 (Stopped, Running)
2 = Circuit 2 (Stopped, Running)
3 = Heat Recovery Status (Disabled, Enabled)
4 = Night Noise Set Back (Off, On)
Digital Outputs
1 = Circuit 1 Fans stages (Off, On) Circuit 1 Enable Output (Off, On)
2 = Circuit 2 Fans stages (Off, On) Circuit 2 Enable Output (Off, On)
3 = Programmable Relay (Off, On)
Analog Outputs
1 = 3-Way valve Output (Value and Output Analog Voltage)
2 = C1 Speed Inverter Output (Value and Output Analog Voltage)
3 = C2 Speed Inverter Output (Value and Output Analog Voltage)
000.0% (00.0V)
000.0% (00.0V)
000.0% (00.0V)
3WV:
DV1:
DV2:
CKT
On
On
FAN1:
FAN2:
PRG Relay:
1
Off
Off
On
2
Off
Off
3
Off
Off
Circuit 1:
Circuit 2:
HR Status:
NNSB:
Running
Running
Enabled
Off
