12 UH-SVX01A-EN
Location
Figure 14. Low Pressure Vapor Or Vacuum
PITCH UP
PITCH UP
RETURN
SUPPLY
GATE VALVE
"LOW PRESSURE
GATE VALVE
F & T TRAP
STRAINER
VAPOR OR VACUUM"
D-6060
