Trane UHSB User Manual

38 UH-SVX01A-EN
Motor Data: P Models
CAUTION
Voltage Selections
Select appropriate AMP, MCA, and
MOP for the multiple voltage
motors. For example, the AMP, MCA,
and MOP for Model 40 with a 230
volt Totally Enclosed motor is 1.1,
1.4, and 2.5 respectively.
Note: All motors are constant
speed and operate at top
speed as indicated in motor
data. Models through 1/8 H.P.
can be run at reduced speed
with addition of optional
variable speed switch. This
switch is factory-calibrated
for low and high speed
ratings, with intermediate
speeds infinitely controllable.
Models 166 through 720
operate at constant speed as
indicated in motor data.
Note: Stated draw is Full Load
(FLA). AMP draw varies by
motor manufacturer ± .2
AMPS. Verify FLA on motor
data plate.
For Table 16
* Optional variable speed switch is available.
** These motors have automatic thermal over-
load protection or impedance protection.
*** These motors are 230/460 volts only.
† Models 336 through 720 are not available for
e
ither Totally Enclosed or Explosion Proof
with Overload 115/1/60 motor types.
Table 16. Standard (Totally Enclosed) Motor Type [MT=1]
Unit Model No. AMP MCA MOP HP RPM
115/1/60† Operating Voltage
42 1.23** 1.6 2.8 1/40* 1550
64 2.1** 2.6 4.7 1/20* 1550
80
102 1.2** 1.5 2.7 1/8* 1070
122
2.3** 2.9 5.2 1/6 1100
146
166
202 3.6** 4.5 8.1 1/4 1100
252 3.6** 4.5 8.1 1/4 1100
280 5.4** 6.8 12.2 1/2 1100
208-230/460/3/60 Operating Voltage
42 0.98-1.1/0.55 1.2-1.4/0.7 2.2-2.5/1.2 1/6 1140
64 0.98-1.1/0.55 1.2-1.4/0.7 2.2-2.5/1.2 1/6 1140
80
102 0.98-1.1/0.55 1.2-1.4/0.7 2.2-2.5/1.2 1/6 1140
122
0.98-1.1/0.55 1.2-1.4/0.7 2.2-2.5/1.2 1/6 1140
146
166
202 1.2-1.4/0.7 1.5-1.8/0.9 2.7-3.2/1.6 1/4 1140
252 1.2-1.4/0.7 1.5-1.8/0.9 2.7-3.2/1.6 1/4 1140
280 1.8-2.0/1.0 2.3-2.5/1.3 4.1-4.5/2.3 1/2 1140
336 3.1-3.2/1.6 3.9-4.0/2.0 7.0-7.2/3.6 3/4 1140
384
500 5.3-5.0/2.5 6.6-6.3/3.1 11.9-11.3/5.6 1-1/2 1160
600
720 9.9-9.8/4.9 12.4-12.3/6.1 22.3-22.1/11.0 3 1165
575/3/60 Operating Voltage
42
0.6 0.8 1.4 1/3 1140
64
80
102
122
146
166
202
252
280 0.8 1.0 1.8 1/2 1140
336 1.3 1.6 2.9 3/4 1140
384
500 2.0 2.5 4.5 1-1/2 1160
600
720 3.8 4.7 8.4 3 1165
Motor Data
