40 UH-SVX01A-EN
Motor Data
*Optional variable speed switch is available.
**These motors are without thermal overload protection.
†230/1/60 unit has 115/1/60 motor supplied with field installed stepdown transformer.
†230/1/60 unit has 115/1/60 motor supplied with field installed stepdown transformer.
Table 18. Totally Enclosed Motor Type
Unit Model No. AMP MCA MOP HP RPM
115/1/60
18, 24, A08, A18 0.8 1 1.8 16W* 1550
A36 1.4 1.8 3.2 1/20* 1000
36, A25 1.2 1.5 2.7 25W* 1550
48, 60, 72 1.4 1.8 3.2 1/20* 1000
84, 96, 108 2.2 2.8 5.0 1/12* 1000
120, 132, 144, 156, 180, 204, 240 4.5 5.6 10.1 1/3 1140
280, 300, 360 5.4 6.8 12.2 1/2 1100
230/1/60
18, 24, A08, A18 0.4 0.5 0.9 16W 1550
A36 1.4 1.8 3.2 1/20† 1000
36, A25 0.6 0.8 1.4 25W 1550
48, 60, 72 1.4 1.8 3.2 1/20† 1000
84, 96, 108 2.2 2.8 5.0 1/12† 1000
120, 132, 144, 156, 180, 204, 240 4.5 5.6 10.1 1/3† 1140
280, 300, 360 5.4 6.8 12.2 1/2† 1100
208-230/460/3/60
48, 60, 72, 84, 96, 108, 120, 132, 144, 156, 180, 204,
240, 280, 300, 360
2.6-2.6/1.3 3.3-3.3/1.6 5.9-5.9/2.9 1/2** 1140
Table 19. Explosion Proof with Thermal Overload Motor Type
Unit Model No. AMP MCA MOP HP RPM AMP MCA MOP HP RPM
115-230/1/60 230/460/3/60
48, 60, 72, 84, 96, 108, 120, 132 3.7 4.6 8.3 1/6† 1140 - - - - -
144, 156, 180, 204 5.4 6.8 12.2 1/4† 1140 2.2/1.1 2.8/1.4 5.0/2.5 1/3 1140
240, 280, 300 7.4-3.7 9.3-4.7 16.7-8.3 1/3*** 1140 2.2/1.1 2.8/1.4 5.0/2.5 1/3 1140
360 7.4-3.7 9.3-4.7 16.7-8.3 1/2*** 1140 2.2/1.1 2.8/1.4 5.0/2.5 1/3 1140
