Installation
UNT-SVX10G-E418
Table 7 - Inlet and outlet connections - FED
FED 100 FED 200 FED 300 FED 400 FED 500 FED 600
Circular connection ø 160 mm
ø 160
1 or 2 2 2 or 3 3 or 4 4 or 5 5 or 6
Circular connection ø 200 mm
ø 200
1 1 or 2 2 or 3 2 or 3 2 or 3 3 or 4
Oblong connection, equivalent ø 250 mm
250mm
111 or 2 1 or 2 22
Rectangular connection for (39 mm deep)
194 x 418 mm 194 x 568 mm 194 x 798 mm 194 x 948 mm
194 x 1098
mm
194 x 1398
mm
Rectangular connection for Trane
discharge grille
(80 mm deep)
152 x 403 mm 152 x 503 mm 152 x 803 mm ---
