9UNT-SVX10G-E4
Installation
Table 3 - General data - FED without air connections
230V/50Hz/1pH, Reversible coil, 2 Pipes
Speed at ESP = 0Pa Unit size 100 200 300 400 500 600
Airflow (1) (m3/h) 310 441 609 1014 1591 1591
S
tandard coil, cooling mode Air inlet conditions : 27°C/47%, Water : 7/12°C, Constant delta T°
Total / sensible cooling capacity (1) (kW) 1.4 / 1.1 1.9 / 1.6 3.3 / 2.5 5.2 / 4.1 6.1 / 4.9 9.7 / 7.3
FCEER / Eurovent Energy class (2) 186 / B 185 / B 174 / B 133 / A 87 / A 125 / A
W
ater flow (1) (l/s) 0.068 0.093 0.16 0.25 0.29 0.46
Water pressure drop (1) (kPa) 18.3 8.2 15.5 39 60.8 48.2
W
ater content (l) 0.5 0.6 1.3 1.5 1.5 2.8
W
ater connection 1/2" ISO R7 female gas
Standard coil, heating mode Air inlet : 20°C, Water inlet : 50°C, Water flow from cooling mode
Heating capacity (1) (kW) 1.9 2.7 4.3 6.9 8 11.4
FCCOP / Eurovent Energy class (2) 240 / B 250 / B 138 / A 173 / A 103 / A 42 / A
Water flow (1) (l/s) 0.068 0.093 0.16 0.25 0.29 0.46
Water pressure drop (1) (kPa) 15.1 6.9 13.6 38 60 48
E
lectric heater (option)
Electric heater (W) - 500 500 / 750 1000 / 3000 1000 / 3000 1000 / 3000
Power supply (V-Ph-Hz) 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50 230-1-50
Power absorbed (speeds 1/3/5) (W) 3.3/5.8/12 3.7/8.7/19 4.8/18/43 8/39/65 36/112/159 36/112/159
A
bsorbed current (min/max) (A) - 2.2 2.2/3.3 4.3/13 4.3/13 4.3/13
Fan motor
Maximun external static pressure (Pa) 50 60 90 90 90 90
Sound levels
Sound Power Level (speeds 1/3/5) (3) (dB(A)) 32/41/49 35/45/53 37/52/61 42/57/62 56/66/69 56/66/69
Sound Pressure Level (speeds 1/3/5) (4) (dB(A)) 23/32/40 26/36/44 28/43/52 33/49/53 46/56/60 46/56/60
NR Level (speeds 1/3/5) (4) 21/28/36 22/31/40 24/38/49 29/44/49 42/54/56 42/54/56
NC Level (speeds 1/3/5) (4) 19/27/34 20/30/38 22/37/47 27/42/47 40/52/50 40/52/50
Voltage range
Minimum voltage (V) 2 2.3 2.6 333
Maximum voltage (V) 5.1 5.8 7.6 997
Speed 1/3/5 -> speed low/medium/high
(1) At high speed in compliance with Eurovent conditions
(2) EER Eurovent ratio and class definition (speed low/medium/high)
(3) Levels according to Eurovent specification 8/2 (ISO 3741/88) and Eurovent FC Certification For 400/500/600 as per voltages declared to Eurovent.
(4) Values calculated from sound levels with hypothetical acoustic attenuation of 9dB
