IPB-99-7-EN-10-6-99 23
Dimensions
WCC030-050F OUTLINE DRAWING — Front
ALL DIMENSIONS ARE IN INCHES (MM)
From Dwg. 21D661772
CABINET
SIZE
MODEL BAYCURB "A" "B" "C" "D" "E" "F" "G" "H"
"B"
WCC030F 030A
14-1/8
(360)
16-5/8
(425)
36
(915)
34
(865)
29-3/16
(740)
13-3/4
(350)
——
"D"
WCC040F
WCC050F
030A
14-13/16
(380)
21
(535)
45
(1145)
34
(865)
33-3/8
(850)
13-3/4
(350)
10-1/8
(261)
9-7/8
(251)
"D"
WCC040F
WCC050F
034A
14-13/16
(380)
21
(533)
45
(1145)
43
(1092)
33-3/8
(850)
13-3/4
(350)
——
