IPB-99-7-EN-10-6-99 9
General
Data Metric Units
MODEL
RATED VOLTS/PH/HZ
A.R.I. RATING
RATINGS (COOLING)
1
BTUH
INDOOR AIR FLOW (CMH)
POWER INPUT (kW)
EER-95 (BTU/WATT-HR.)
6
EER-82
NOISE RATING NO.
2
RATINGS (HEATING)
1
(HIGH TEMP.) CAPACITY (WATTS) - COP
POWER INPUT (kW)
(LOW TEMP.) CAPACITY (WATTS) - COP
POWER INPUT (kW)
HSPF (BTU/WATT-HR.)
6
POWER CONNS. — V/PH/HZ
MIN. BRCH. CIR. AMPACITY
3
FUSE SIZE - MAX.(AMPS)
FUSE SIZE - RECMD. (AMPS)
COMPRESSOR
NO. USED - NO. SPEEDS
VOLTS/PH/HZ
R.L. AMPS
L.R. AMPS
BRCH. CIR. SELEC. CUR. AMPS
OUTDOOR COIL — TYPE
ROWS / FINS PER MILLIMETER
FACE AREA (SQ. M)
TUBE SIZE (IN.)
REFRIGERANT CONTROL
INDOOR COIL — TYPE
ROWS / FINS PER MILLIMETER
FACE AREA (SQ. M)
TUBE SIZE (IN.)
REFRIGERANT CONTROL
DRAIN CONN. SIZE (IN.)
DUCT CONNECTIONS
OUTDOOR FAN — TYPE
NO. USED / DIA. (MM)
TYPE DRIVE / NO. SPEEDS
CMH @ 0.0 PASCALS
4
NO. MOTORS - HP
MOTOR SPEED R.P.M.
VOLTS/PH/HZ
F.L. AMPS - L.R. AMPS
INDOOR FAN — TYPE
DIA. X WIDTH (MM)
NO. USED
DRIVE / SPEEDS (NO.)
CMH VS. PASCALS
5
NO. MOTORS - HP
MOTOR SPEED R.P.M.
VOLTS/PH/HZ
F.L. AMPS - L.R. AMPS
FILTER — FURNISHED?
TYPE RECOMMENDED
NO. - SIZE - THICKNESS
REFRIGERANT
CHARGE (KG OF R-22)
DIMENSIONS
CRATED (MM)
UNCRATED
WEIGHT
SHIPPING (KG) / NET (KG)
WCC030FD00B
380-415/3/50
9085
1690
3.12
9.50 / 10.00
10.90
8.0
8675 - 3.12
2.78
4572 - 2.00
2.29
6.80
380-415/3/50
10.2
15
15
CLIMATUFF
®
1 - 1
380-415/3/50
5.7
51
4.2
PLATE FIN
2 / .591
.801
3/8 COPPER
TXV BLEED
PLATE FIN
3 / .591
.368
3/8 COPPER
ORIFICE - .071
3/4 FEMALE NPT
SEE OUTLINE DRAWING
PROPELLER
1 / 457
DIRECT / 1
3448
1 - 1/2
900
380-415/1/50
1.7 - 3.8
CENTRIFUGAL
254 X 229
1
DIRECT / 2
SEE FAN PERFORMANCE TABLE
1 - 1/3
900
380-415/1/50
1.1 - 2.6
NO
THROWAWAY
3 - 254 x 635
3.72 KG
H X W X D
895 X 965 X 1448
SEE OUTLINE DRAWING
184 / 166
WCC040FD00B
380-415/3/50
11606
2240
4.10
9.70 / 10.00
10.95
8.4
11547 - 3.18
3.66
6067 - 2.06
2.96
6.80
380-415/3/50
13.8
20
20
CLIMATUFF
®
1 -
380-415/3/50
8.0
51
7.1
PLATE FIN
2 / .591
1.30
3/8
TXV BLEED
PLATE FIN
4 / .591
.502
3/8
ORIFICE- .082
3/4 FEMALE
SEE OUTLINE DRAWING
PROPELLER
1 / 559
DIRECT / 1
4785
1 - 1/2
900
380-415/1/50
1.7 - 3.8
CENTRIFUGAL
279 X 279
1
DIRECT / 2
SEE FAN PERFORMANCE TABLE
1 - 3/4
900
380-415/1/50
2.1 - 4.8
NO
THROWAWAY
3 - 254 x 635
5.90 KG
H X W X D
1000 X 1194 X 1676
SEE OUTLINE DRAWING
254 / 236
WCC050FD00B
380-415/3/50
15122
2830
5.53
9.35 / 10.00
11.15
8.4
15709 - 3.18
4.91
9173 - 2.16
4.21
6.80
380-415/3/50
16.3
25
25
CLIMATUFF
®
1 -
380-415/3/50
9.8
71
10.0
PLATE FIN
2 / .591
1.30
3/8
TXV BLEED
PLATE FIN
4 / .591
.502
3/8
ORIFICE - .096
3/4 FEMALE
SEE OUTLINE DRAWING
PROPELLER
1 / 559
DIRECT / 1
4783
1 - 1/2
900
380-415/1/50
1.7 - 3.8
CENTRIFUGAL
279 X 279
1
DIRECT / 2
SEE FAN PERFORMANCE TABLE
1 - 3/4
900
380-415/1/50
2.1 - 4.8
NO
THROWAWAY
3 - 254 x 635
5.44 KG
H X W X D
1000 X 1194 X 1676
SEE OUTLINE DRAWING
263 / 244
NOTES:
1
RATED IN ACCORDANCE WITH A.R.I. STANDARD 210/240.
2
CALCULATED IN ACCORDANCE WITH A.R.I. STANDARD 270.
3
CALCULATED IN ACCORDANCE WITH CURRENTLY PREVAILING NATL. ELECTRIC CODE.
4
STANDARD AIR - DRY COIL - OUTDOOR
5
STANDARD AIR - WET COIL - INDOOR
6
RATED IN ACCORDANCE WITH D.O.E. TEST PROCEDURE. HSPF IS AT THE
MINIMUM DESIGN REQUIREMENT FOR REGION IV.
