Trans instruments WalkLAB HP 9010 - Product Layout

2
TO CLOSE BATTERY COVER
1 Align arrow to top of casing
2 Press here to snap down cover
4. PRODUCT LAYOUT:
pH Electrode
Socket
Temperature
Probe Socket
Battery Cover
Lift up
latch
here to
open
Battery
Cover
On/Off Button
Press once to switch ON.
To switch OFF, press and hold-down.
Liquid
Crystal
Display
Buttons
correlate
to display
Legend
