Disassembly
100-13732 - Rev B Page 37
Disassembly of Major Components
The Ithaca
®
9800 printer has the capability to quickly and easily load different
printer mechanisms to support thermal printing of different sizes of labels. This
section discusses how to open the unit and remove and change the printer
mechanism.
1. Press the power switch on the side of the terminal to turn it OFF as shown.
