Parts List
Page 46 100-13732 - Rev B
ITEM
QTY
PART NUMBER
DESCRIPTION
1
1
97-11035
HEAT SINK (ASSY)
2
4
98-02592
2-32 X 1/4 PAN HD PLASTITE HI-LO
3
1
97-10627L
9700 MECH BOARD ASSEMBLY ROHS
4
1
97-10964L
ASSY - MOTOR
5
1
97-10966L
ASSY - PAPER OUT SENSOR
6
1
97-11024
BRACKET - LATCH
7
1
97-11040
BRACKET - PC BOARD (ASSY)
8
1
97-11031
BRACKET - HEAD
9
2
20-03152
BUSHING - VALIDATION SHAFT
10
1
97-11069
CABLE - PRINT HEAD (FOLDED)
11
1
97-11030
COVER - PRINTER (ASSY)
12
1
97-11016
FLAG - COVER OPEN
13
1
97-11019
GEAR - 18 TOOTH
14
1
97-11023
GEAR - 36/18 TOOTH
15
1
95-05776
GEAR - 54/16 TOOTH
16
1
97-11037
GUIDE - PAPER
17
1
97-11042
GUIDE PAPER (TOP)
18
1
97-11022
HINGE - COVER
19
1
97-11582
LABEL - ITHACA 9700 PAPER LOAD
20
1
97-11012
LATCH - COVER
21
1
97-11013
PAPER - PATH
22
1
97-11038
PIN - PIVOT
23
1
97-11049
PIN - PIVOT (COVER OPEN)
24
2
97-11008
PIVOT PIN
25
1
97-11044
PLATE - SPRING
26
1
97-11009
RING - RETAINING
27
1
97-11025
PRINTER - FRAME
28
8
520-9800002
RING - RETAINING
29
1
520-9800003
RING - RETAINING
30
1
98-04997
SCREW - 4-24 (.187) PHPS PHD
31
3
98-7608
SCREW - #4 PLASTIC THREAD FORMING
32
2
98-1182
SCREW - M2.6 x 4mm PHPS PHD
33
9
98-02215
SCREW - M3 x 6MM SEMS PHPS PHD
34
1
97-11061
SPRING - COVER OPEN
35
1
97-11056
SPRING - COVER (TORSION)
36
1
97-11028
SPRING - FLAT, LATCH
37
2
97-11046
SPRING - PRINTHEAD COMPRESSION
