TransCore encompass 4 - Page 14

Quick Start Guide
TransCore Proprietary 14
Table 10 Sense Input/Output Cabling Assignments
Pair Pin Color Signal Description Typical Function
Blue/Black
R Blue Sense Input1 Sense Input1
General-purpose sense
input, not used for
detecting presence
S Black Sense Input1_RTN
Sense Input1 return;
not isolated from signal
ground
General-purpose sense
input, not used for
detecting presence
Brown/Black
T Black Sense Output0_COM
Sense Output0 (tag
detect), common
terminal
Switched output to
control gate
U Brown Sense Output0_NO
Sense Output0
normally open terminal
Switched output to
control gate
Orange/ Black
V Black Sense Output0_COM
Sense Output0
(tag detect output),
common terminal
Switched sense output
for any external control
(light, gate, buzzer, etc.)
W Orange Sense Output0_NC
Sense Output0
normally closed
terminal
Switched sense output
for any external control
(light, gate, buzzer, etc.)
Green/Black
X Black Sense Output1_ COM
Sense Output1,
common terminal
Switched sense output
Y Green Sense Output1_NO
Sense Output1
normally open terminal
Switched sense output
White/ Black
Z Black Sense Output1_ COM
Sense Output1,
common terminal
Switched sense output
a White Sense Output1_NC
Sense Output1
normally closed
terminal
Switched sense output
