Quick Start Guide
TransCore Proprietary 20
Table 11 Frequently Used Reader Commands
Enter Reader Response What It Does
#646xx
(00 – 0F)
Hex
#Done
where xx = 00 to 0F (hex)
Set IAG Attenuation. Allows control of the
read zone for IAG tags. Does not aect the
performance of other tag types. 00=max power
for max range (04 Default)
#647xxx #Done
Set RF operating frequency, 0.25 MHz
Resolution, #6470DC = 915MHz (Default). Refer
to Table 5.
#66F #Done
Load default operating parameters
(does not aect RF operating frequency)
#863hhhh #Done
Set facility code value (4 hex chars) (factory
default = 0000)
#870 #Done Disable wiegand conversion (factory default)
#871 #Done Enable 26 bit format
#872 #Done Enable 32 bit LSU format
#873 #Done Enable 34 bit Cardkey format
#874 #Done Enable 35 bit HID format
#875 #Done Enable 37 bit McGann format
#878 #Done Disable fixed facility code (factory default)
#879 #Done Enable fixed facility code
Troubleshooting
Communications problems between the reader and back-end host
These problems may be caused by incorrectly wiring the communications cable, using the wrong cable,
having a too-long cable run, or incorrectly setting communications parameters between host and reader.
Cable run for RS–232 exceeds 50 feet in length
Fifty feet exceeds the maximum length for RS–232 interface. The interface should be converted to
RS–422, wireless modem, fiber optic, or Wiegand.
Long RF cable runs to antennas
For the external antenna-series Encompass 4 Readers, long RF cable runs between the reader and
the antenna may cause signal degradation or loss. This scenario may be site-specific, but TransCore
recommends limiting antenna cable runs to less than 3dB of cable loss.
