Table 11 Frequently Used Reader Commands
Enter Reader Response What It Does
#531 #WC x FFC y Val hhhh
Where x = 0 through 5 to line up with
#870 through #875 commands above.
y = 0 Disabled fixed facility code
y = 1 Enabled fixed facility code
hhhh = Fixed Facility code value
(Decimal)
Display Wiegand Translator conversion settings
See Commands #870-#879, #863
#532 #TOF <0 to 1>, see #450, #451
0 = Wiegand disabled
1 = Wiegand enabled
Display Wiegand mode status
#533
#WTI <01 to FF>
seconds (1-255) in hex, see #46NN
Display Wiegand retransmit interval
#570 #ATA:_ eGo: _ SeGo: _ IAG:_ EPC:_
SORT: _TMM:_
I = SeGo ID (64 bits)
E = enabled
F = full transaction
D = disabled
See commands #480 through #489
Display reader protocols
#63 #Model [model]
Ver [version no.] SN [serial no.]
Copyright [date]
TransCore
Reset reader equivalent to cycling power. Does
not aect operating parameter settings
#6400
#Done Turn RF o
#6401
#Done Turn RF on
#641
#Done Select RF-by-input control (Default)
#642NN
(00 – FF)
#Done
Set RF operating frequency, 0.5 MHz resolution:
915MHz = #6421A (Default). Refer to Table 5.
#643NN
(00-1F)
#Done
Set operating range for ATA protocol (distance):
(00 to 1F Hex) 1F = max range (Default)
#644NN
(00 – 14)
Hex
#Done
Set RF attenuation in 1.0 dB increments; 0 to 20
dB, 00=max power for max range
#645NN
#Done
Set operating range for eGo and SeGo
protocols
