Encompass 4 Reader

TransCore Proprietary

Apply Power

Apply power and verify the reader sign-on message appears on the terminal emulator application

laptop/computer.

Reader Set Up

1. Use reader commands to query status and set up the reader.

2. Make sure that each reader is set up to the appropriate settings.

3. Adjust reader angle and power to optimize read zone for each reader.

4. Check for interference from each reader or the environment, using a portable ﬁeld spectrum analyzer

if one is available.

Note: If using Wiegand tags, conﬁgure the reader for Wiegand operation and connect the

Wiegand interface. Refer to “Conﬁgure for Wiegand Operation” on page 11.

5. Disconnect the computer and connect the reader to back end devices. Recheck read zone and for

interference between readers.

6. System-test the reader to verify that the gate opens when a valid tag is read.

7. Once all in lane testing is complete, perform a system test using tagged vehicles passing through

numerous lanes. The tag reads are sent to the gate controller back end system for validation.

Reader Commands

Table 11 provides the commands frequently used in testing, setting up, and tuning the Encompass 4

Reader.

NOTE: An #Error response from the reader indicates that the command was entered incorrectly.

Table 11 Frequently Used Reader Commands

Enter Reader Response What It Does

#00 #Done Returns reader to data mode

#01 #Done Switches to command mode

#40 #Done

Transmits all tag IDs without regard for

uniqueness

#450 #Done Disable Wiegand mode (Default)

#451 #Done Enable Wiegand mode, See #532

#454 #Done Disable Multitag Sort (Default)

#455 #Done Enable multi-tag sort

#46NN #Done

Set Wiegand retransmit interval in seconds

NN = 01–FF Hex (01 Default) See#533
