3200B SERIES OPERATION MANUAL
TRANSMILLE LTD. Page 32
Step 5 Press the soft key TIME, use the range up / range down buttons,
digital control or enter the required time via the numeric keypad and
press enter.
Step 6 Press the soft key TEST
The following screen will appear
Step 7 Press the test button on the RCD tester to allow the 3200B to
measure the current.
Step 8 Read the measured current from the display of the 3200B.
Timing duration
Measured RCD current
Positive phase start
Measurement indication
