3200B SERIES OPERATION MANUAL
TRANSMILLE LTD. Page 71
PCB Removal (Not required to gain access to internal fuses).
The main PCB can only be removed from the front of the case by removing the front
panel.
Processor Board
Plugs into the main PCB and controls all functions within the calibrator. The
processor also manages all calibration constants held in memory. Calibration
constants are stored twice to prevent errors - the processor runs a self test to detect
malfunction and overloads.
Warning
Removal of the processor board may corrupt the calibration constants.
