3200B SERIES OPERATION MANUAL
TRANSMILLE LTD. Page 8
Designed for use in the laboratory or portable on-site calibration.
The 3200B calibrator is suitable for use in the standards laboratory. The fast warm
up time combined with the small case and low weight make the 3200B series
calibrator also ideal for onsite calibration. The serial interface allows direct
connection to a PC/laptop.
Retro fit options allow extra functions to be added.
Several internal retro fit options including increased resistance range (up to 10GΩ)
for Insulation testers, auto loop, high accuracy resistance and external resistance
input allow the user to select the most cost effective solution for the calibration work
with the ability to add extra functions at a later date.
USB Interface as standard.
All functions and outputs of the 3200 calibrator are fully programmable over the USB
interface. The use of the USB interface saves the cost of fitting GPIB cards to the
PC, and also allows easy connection to portable PC’s, reducing the set up time for
on-site calibration.
Input / Output Connection
The input and output terminal configuration has been designed to enable simple
connection to a full range of instrumentation. Use of a dedicated socket directly on
the front panel allows resistance measurement functions such as LOOP testing to
be calibrated to include residual values right up to the socket.
All outputs are isolated when not in use, with an LED indicator showing the active
input / output terminal(s).
