REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
101 PW04 PW, M4 2
102 TB-102 Heater Arm 1
103 TB-103 Pin 1
104 HN08 HN, M8 1
105 ER06 Snap Ring, E-6 1
106 HBS0440H HBS, M4×40 (H) 2
107 TB-107 Side Plate 1
113 TB-113 Heater Ass'y 1
114 TB-114 Return Spring 1
115 TB-115 Spring 1
117 TB-117 Roller 4
118 TB-118 Shaft (For Inside Tension Adjustment) 1
TB-118A Shaft (For Outside Tension
Adjustment)
1
119 SR15 Stop Ring, S-15 10
120 KYA050515 Key, 5×5×15 9
121 HSS0506G HSS, M5×6 (G) 2
122 TB-122 Shaft 1
123 TB-123 Holder 1
124 TB-124 Pin 1
125 HSS0606G HSS, M6×6 (G) 1
126 HSS0508G HSS, M5×8 (G) 3
127 TB-127 Gear 3
128 TB-128 Collar 7
129 TB-129 Feed Gear 1
130 TB-130 Spring 1
131 HB06100 HB, M6×100 1
132 HN06 HN, M6 12
133 TB-133 Nut 1
134 TB-134 Gear 1
135 TB-135 Holder Arm 1
136 HBS0616 HBS, M6×16 4
137 TB-137 Shaft 1
138 KYA050520 Key, 5×5×20 2
139 TB-139 Pulley 1
140 RR22 Snap Ring, H-22 1
-8-
