Transpak TP-202CE - Page 45

REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
1 TD-001 Protection Cover 1
2 TC-002 Bracket 1
3 TD-003 Reel Shaft 1
4 TC-004 Package Guide 1
5 TC-005 Lid 5
6 TC-006 Caster (Free) 2
7 TC-007 Caster (Brake) 2
8 TC-008 Grommet 1
9 TC-009 Brake Shaft 1
10 BR6003ZZ Bearing, 6003ZZ 2
11 TC-011 Washer 1
13 TC-013 Inner Flange 1
14 TC-014 Outer Flange 1
15 TC-015 Protector 1
16 TD-016 Reel Nut Handle (LH) 1
18 TD-018 Brake Lining 1
19 TC-019 Roller 2
20 TC-020 Pin 1
21 TC-021 Split Pin 1
22 TC-022 Roller Holder 1
24 TD-024 Spring Hook 1
25 TC-025 Spring 1
38 TMS0508 TMS, M5×x8 6
39 SW16 SW, M16 4
41 TD-041 Body Frame 1
TK-041 Body Frame (Only CE) 1
42 TC-042 Support 1
43 TC-043 Top Plate 1
44 TD-044 Reel Support 1
45 TC-045-1 Fixing Brake Lining Bracket 1
46 TD-046-1 Arm 1
47 TD-047 Roller Bracket 1
48 TD-048 Shaft 1
49 TD-044A Reel Support Ass'y 1
-22-
