REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
1 TG-001 Power Switch 1
2 TG-002 Variable Resistor (1MΩ)2
3 TG-003 Knob 1
4 TG-004 Reset Push Button Switch 1
5 TG-005 Feed Push Button Switch 1
6 TG-006 Control Panel 1
7 T2-6-30250 PC Board 1
8 TG-008 PC Board Receptacle 1
9 TG-009 Base 1
12 TG-012 Knob 1
13 TG-013 Fuse Holder 1
14 T6-6-30133 Fuse (10A)(For 110V AC) 1
T6-6-30034 Fuse (7A)(For220V/230V/240V AC) 1
15 TG-015 Transformer (For 110V) 1
TG-015-1 Transformer (For 220V) 1
TG-015-2 Transformer (For 240V) 1
16 TG-016 Bolt 1
19 TG-019 Power Cord 1
20 LA-10018 Label 1
21 TG-021 Switch Cover 1
22 TG-022 Grommet 1
23 LA-40001 Label 1
24 LA-40003 Label 1
30 LA-20170 Label 1
34 TG-034 Cover 1
51 TMS0408 TMS, M4×8 8
52 HN04 HN, M4 2
53 TMS0312 TMS, M3×12 2
61 TK-001 Main Power Switch (Only CE) 1
62 PW04 PW, M4 2
63 PMS0408 PMS, M4×8 2
64 SW03 SW, M3 2
05/2010
-37-
