1-6 TENSION GROUP T6-1-60000
REF.
NO.
PART NO. DESCRIPTION Q'TY REMARKS
1 T6-1-60110 Tension Arm Shaft 1
2 T6-1-60120 Tension Arm Spring 1
3 T6-1-60130 Tension Adjusting Arm Spring 1
4 T6-1-60140 Tension Arm Spacer 1
5 T6-1-60150 Strap Cover 1
6 T6-1-60160 Tension Arm Spring Hook L-Type 1
7 BRHK2516 Bearing, HK2516 2
8 ER15 Snap Ring, E-15 2
11 BRIR202517 Bearing, IR202517 2
20 SP0680 Spring Pin, 6x80 1
41 T6-1-61000 Tension Arm Ass'y 1 SEE PAGE 22
42 T6-1-62000 Tension Jaw Ass'y 1
T6-1-62000S
Tension Jaw Ass'y (Stainless Steel Model) 1
43 T6-1-63001 Tension Adjusting Cam Ass'y 1 SEE PAGE 24
44 T6-1-64000 Tension Adjusting Ass'y 1 SEE PAGE 25
45 T6-1-65000 Tension Adjusting Arm Ass'y 1 SEE PAGE 26
46 T6-1-63000 Tension Adjusting Cam Ass'y (Option) 1 SEE PAGE 23
52 HBS0512 HBS, M5x12 2
53 HN08 HN, M8 2
55 SW05 SW, M5 2
56 PW05 PW, M5 2
-21-
