CAUTION
* Be careful to strangulation due to cables and hoses, particularly due to excessive length.
* At least 30 min required for ME equipment to warm from the minimum storage temperature between
uses until it is ready for intended use. At least 30 min required for ME equipment to cool from the
maximum storage temperature between uses until it is ready for intended use.
* This equipment needs to be installed and put into service in accordance with the information provided in
the ACCOMPANYING DOCUMENTS;
* Wireless communications equipment such as wireless home network devices, mobile phones, cordless
telephones and their base stations, walkie-talkies can affect this equipment and should be kept at least a
distance d away from the equipment. The distance d is caculated by the MANUFACTURER from the 800
MHz to 2.5 GHz column of Table 6 of IEC 60601-1-2:2007,as appropriate.
* Please use ACCESSORIES and detachable partes specified/ authorised by MANUFACTURE.
Otherwise, it may cause damage to the unit or danger to the user/patients.
* There is no luer lock connectors are used in the construction of tubing, there is a possibility that they
might be inadvertently connected to intravascular fluid systems, allowing air to be pumped into a blood
vessel.
* Please use the device under the environment which was provided in the user manual. Otherwise, the
performance and lifetime of the device will be impacted and reduced.
6
7
INTRODUCTION
LCD display signal
INTRODUCTION
SYMBOL DESCRIPTION
Systolic blood pressure High pressure
Diastolic blood pressure Low pressure
EXPLANATION
Pulse Pulse/minute
Deflating
CUFF is deflating
Current Time
Time(year:month:day:hour:minute)
Memory
If “MEM” shows, the displayed measurement
values is from the memory.
mmHg
Measurement Unit of the blood pressure
Heartbeat Heartbeat dectetion during measurement
Data pending to transmit
Measurement data stored in the equipment
Shocking reminder
Shocking will result in inaccurate
Bluetooth icon
The bluetooth icon blinks when the
bluetooth is working
Measurement Unit of the blood pressure
(1kPa=7.5mmHg)
kPa
(1mmHg=0.133kPa)
PUL
/min
DIA
mmHg
SYS
mmHg
DIA
SYS
PUL
/min
Low battery
Batteries are low and need to be replaced
Blood pressure monitor is detecting an
irregular heartbeat during measurement.
Irregular heartbeat
