Trek Domanee 2017 - 5 INSTALLING THE SHIFT CABLES

5 INSTALLING THE SHIFT CABLES
TOOLS AND MATERIALS REQUIRED:
• Shift cables
• Housing
• Housing end caps
• Dropout cable sleeve
• Inline barrel adjuster
• Housing cutters
• 4mm wrench
• Cable cutters
1. Pull the hood of the non-drive side cover back to
reveal the cable port. Open the gray access panel.
2. Pull the rear derailleur cable through the opening
of the shifter bracket, seating the cable head
through the slot.
3. Install housing caps onto cable housing. Insert the
cable housing into the shifter cable stop.
4. Guide the cable housing tightly along the
handlebar, stopping a few inches short of the stem.
5. With the handlebar rotated all the way to the non-
drive side, align the cable.
13
