Trek SUPERCALIBER SL - Cable Routing: SL AXS Shifting; Rear Brake Hose Routing; IsoStrut Lockout Cable Housing; Dropper Seatpost Cable Housing

2024 Supercaliber
9
SL routing with AXS shiing
Important:
Route the cables as
shown below.
6
1
2
3
5
4
Cable tunnels
molded into
the frame
4
1
Rear brake hose
2
IsoStrut lockout cable housing
3
Dropper seatpost cable housing
4
Cable housing plugs — W600649
5
Chainstay plug — W5259425
6
Chainstay plug — W600209
