Trek SUPERCALIBER SL - Frame Guards; Rotor and Chainring Strike Guards; Chainstay and Downtube Guards; Adhesive Guard Application

2024 Supercaliber
11
Frame guards
1
2
3
4
1
Rotor strike guard, bonded — W5307943
2
Chainstay guard, adhesive — W5307370
3
Chainring strike guard, bonded — W5307942
4
Downtube protector, clear adhesive — W5312789
Adhesive guards
2 4
Use isopropyl alcohol to clean the frame surface where the
guards attach. Wait for the alcohol to dry before applying
the guards.
NOTICE: Do not clean the entire frame with isopropyl
alcohol. Isopropyl alcohol could damage the paint.
Bonded strike guards
1 3
1. To improve adhesion, use sandpaper to roughen the
backside of the guards and/or remove remnants of
the old guard from the areas of the frame where epoxy
will be applied.
2. Attach the guards with a two-part epoxy.
3. Allow the guards and epoxy to cure for 24 hours.
