Trek SUPERCALIBER SL - Rear Axle Installation (SRAM Transmission); Switch Lever and Thru Axle; Dropout Brake Mount; SRAM Transmission Derailleur

2024 Supercaliber
4
Rear axle with SRAM Transmission Derailleur
1
2
3
10Nm
4
6
5
1
Switch lever — W573860
2
Thru axle, 12x180 — W5290786
3
Dropout brake mount — W5307257
4
SRAM Transmission Derailleur
— Refer to information on sram.com.
5
Bushing
6
Mounting bolt
For additional information about the Transmission derailleur, refer to the SRAM user manual at sram.com.
