1 x 22mm Spanner (N)
1 x Moulded carry case
1 x Instruction manual
• Check for damage to the tool, parts or accessories
which may have occurred during transport.
• Take the time to thoroughly read and understand this
manual prior to operation.
MARKINGS ON TOOL
The following pictograms are shown on the tool:
Read instruction manual before use.
Wear ear protection.
Wear eye protection.
Visible radiation. Do not stare into light.
Double insulation
DESCRIPTION OF PARTS - (Fig. A)
WARNING: Never modify the power tool or
any part of it. Damage or personal injury could result.
1. Variable speed dial
2. Main handles
3. Depth stop rod
4. Depth stop locking knob
5. Spindle lock
6. Collet
7. Depth stop turret
8. Router base
9. Micro-adjustable side fence
10. Height stop rod
11. Thumb wheel
12. Height adjuster
13. Spanner
14. Fine height adjustment knob
15. Fine height adjustment gauge
16. Plunge locking lever
17. Side fence locking knobs
18. Router table safety clip insertion point
19. On/off trigger switch
20. On/off trigger switch release button
Intended Use
The T8 router has been designed for trade/medium duty
routing of wood, wood based materials and plastics.
These routers are intended for routing grooves, edges,
profiles and slots as well as copy routing.
DO NOT use under wet conditions or in the presence of
flammable liquids or gases.
The T8 is a professional power tool.
The T8 is designed so that they can be installed into a
router table. The router may only be installed in tables
that meet the legal safety requirements for router tables.
DO NOT let children come into contact with the tool.
Supervision is required when inexperienced operators
use this tool.
• Young children and the infirm. This appliance is not
intended for use by young children or infirm persons
without supervision.
• This product is not intended for use by persons
(including children) suffering from diminished physical,
sensory or mental abilities; lack of experience,
knowledge or skills unless they are supervised by a
person responsible for their safety. Children should
never be left alone with this product.
CAUTION: Before operating any of the
controls, read the following sections.
Plunge Locking Lever (Fig. B1-B2)
1. Lever (16) Position (12-3 O’clock)
Plunge setting is locked and cannot move.
2. Lever (16) Position (6 O’clock)
Plunge lock is disengaged.
Perfect for fast repositioning and surface registration
when used with a jig.
How to fit the Collet sleeve - (Fig. C2)
This router is supplied with a collet sleeve as an accessory.
To fit the collet sleeve (b) simply slide it into the collet (a).
The collet sleeve has a flange to ensure insertion to
correct depth.
NOTE: Do not attempt to remove the collet from the
collet nut.
Depth Stop Turret - (Fig. E)
WARNING: Do not change the depth stop
turret while the router is running. This will place your
hands too near the cutter head.
The depth stop turret (7) limits the downward distance
that the tool can be plunged. It serves to define the
depth of cut by limiting the travel of the depth stop rod (3).
1. The cutting depth can be set by turning the appropriate
height on the depth stop turret.
2. The depth stop turret is rotatable with stepped stops.
3. It is the interaction of the depth stop rod and the
depth stop turret that determine the routing depth.
4. Refer to section Adjusting the Depth of Cut for
