To set up for fine height adjustment:
1. Plunge router and lock the plunge locking lever..
2. Rotate the thumb wheel (11) up the height stop rod
until it is close to the router casting fork (62).
3. Align the base of the thumb wheel (11) so that it will
locate in the fork (62).
4. Release plunge locking lever.
CAUTION: DO NOT use a powered drill to
drive the height adjuster assembly. Only use the supplied
handle. Ensure that the plunge locking lever is unlocked.
Never use unnecessary force to rotate the mechanism.
Do not undo Torx® screw on hex nuts.
Using Without the Height Adjuster -
(Fig. S2)
In portable use the thumb wheel (11) should be wound
to the top of the height stop rod and hand tightened
against the hex cap. The base of the knurled nut (11)
should be aligned with the fork (62) in the router casing.
CAUTION: In normal plunge mode, ensure
the base of the knurled nut is aligned correctly with the
forks of the lower motor housing. This will enable the
cutter to retract into the base safely.
For Portable Use:
1. Place the height adjuster (12) onto the top threaded
spindle hex nut (51).
2. Rotate handle clockwise to raise motor body and
reduce cutter depth.
3. Rotate handle anti-clockwise to lower motor body and
increase cutter depth.
For Router Table Use - (Fig. S3)
1. Ensure router is fitted into the router table, see
opposite page.
2. Place height adjuster (12) through router table hole
onto bottom threaded spindle hex nut (64).
3. Rotate handle clockwise to raise motor body and raise
cutter height.
4. Rotate handle anti-clockwise to lower motor body and
lower cutter height.
One revolution corresponds to 1.5mm. The height
adjuster handle dial (63) can be reset to zero.
Prior to Operation
1. Check that the cutter is correctly installed in the collet.
2. Set the cutting depth.
3. Connect a dust extractor.
4. Make sure the plunge locking lever is locked before
switching on.
Routing with Bearing Guided Cutters
- (Fig. R)
Where a parallel guide or guide bush are inappropriate, it
is possible to use bearing guided cutters (50) for cutting
shaped edges.
Trend offer a wide range of bearing guided cutters for
various applications. Please see trend-uk.com for details.
Trend Base Configuration - (Fig. N)
This router has three threaded holes (53) built into the
base that allows it to attach to other Trend accessories.
MAINTENANCE
Your power tool has been designed to operate over a
long period of time with a minimum of maintenance.
Continuous satisfactory operation depends upon proper
tool care and regular cleaning.
WARNING: To reduce the risk of serious
personal injury, turn tool off and disconnect
tool from power source before making any
adjustments or removing/ installing attachments
or accessories. An accidental start-up can cause
injury.
Repairs
WARNING: To assure product SAFETY
and RELIABILITY,repairs, maintenance and adjustment
(including power cord repairs, and brush inspection and
replacement, when applicable) should be performed by a
Trend service centre or a Trend authorized service centre.
Always use identical replacement parts.
Lubrication
• Your power tool requires no additional lubrication.
Cleaning
WARNING: Blow dirt and dust out of
the main housing with dry air as often as dirt is seen
collecting in and around the air vents. Wear approved
eye protection and approved dust mask when
performing this procedure.
WARNING: Never use solvents or other
harsh chemicals for cleaning the non-metallic parts of
the tool. These chemicals may weaken the materials
used in these parts. Use a cloth dampened only with
