Page 4
LED Indicators
The Print Server has LED indicators on the top. The Error LED is red. The Status indicator LED is green. The LED indicator modes
are described in the following table.
Status LED
(Green)
Error LED
(Red)
Status Description
Off Off No power.
On Off Normal operation - Idle.
Flashing Off
Normal operation - transmitting or receiving
packets from the network.
On On No printer connected.
Flashing Flashing Firmware upgrade in progress.
Diagnostic Push Button
The button is recessed; a pin or paper clip can be used to press it. This button has 2 functions:
Restore the factory default settings
Print a test page containing all current settings.
