3
3. LEDs
100M/1000M
Green: Connection for the port is 2000Mbps (Full)
Amber: Connection for the port is 100/200Mbps (Half/Full)
Not Illuminated: Connection for the port is 10/20Mbps
(Half/Full) or nothing is detected on the port
Power
Green: Power is on
Not Illuminated: Power is off
10M/LINK/ACT
Green (Solid): Link to another device
Green (Blinking): Activity is occurring from the link
Not Illuminated: Nothing is detected on the port
