HARDWARE INSTALLATION
Front Panel
The figure below shows the front panel of the Wireless Broadband Router.
TEW-432BRP Front Panel
POWER
This indicator lights green when the hub is receives power, otherwise it is off.
SYSTEM
This indicator blinks green means the Internet Broadband Router is working
successful. Otherwise, this indicator always on or off means the function of the
Internet Broadband Router is fail.
WAN (Link/ACT)
The indicators light green when the WAN port was connected to an xDSL/Cable
modem successfully.
The indicators blink green while the WAN port was transmitting or receiving data
on the xDSL/Cable modem.
WLAN (ACT)
This indicator lights green when there are wireless devices connected and
transmitting data to the Wireless Router.
LAN (Link/ACT)
These indicators light green when the LAN ports were connected successfully.
These indicators blink green while the LAN ports were transmitting data.
