TRENDnet TEW-735AP Quick Installation Guide

3
5. Enter a new password, verify the new
password and click Next.
6. Select an IP address for the access point
within the same subnet as your default
gateway and then click Apply.
7. Setup is complete.
Note:
For detailed information regarding the access
point configuration and advanced settings,
please refer to the User's Guide CD-ROM.
Preset
Wireless Settings
Wi-Fi Name/SSID
XXXXXXXXXXXXX
Wi-Fi Key
XXXXXXXXXXXXX
Management Login
http://tew-735ap
username: admin
password: xxxxxxxx
4. Enter the Username and Password. By
default: Username: admin; Password: admin.
Select the desired language and then click
Login.
Note:
For added security we have pre-encrypted each
TEW-735AP with a unique Wi-Fi Name (SSID)
and Wi-Fi Key. You can find these
pre-configured settings on the labels at the front
and back of the TEW-735AP. You will use this
information to connect wireless to the access
point. To change the Wi-Fi Key, refer to the
product manual. If the access point is reset, the
Wi-Fi Key and the Wi-Fi Name will also reset to
factory defaults.

TRENDnet TEW-735AP Specifications

General

Modulation	-
Frequency band	2.4 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11az, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Internal	No
Certification	CE, FCC
WAN connection	Ethernet (RJ-45)
Security algorithms	WPA2
Operating temperature (T-T)	0 - 45 °C
Power supply	12 W
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Cables included	LAN (RJ-45)
Antenna features	Integrated antenna
Antennas quantity	2
Antenna gain level (max)	4 dBi

Weight and Dimensions

Depth	60 mm
Width	128 mm
Weight	210 g
