TRENDnet TEW-740APBO Quick Installation Guide

1
1. Before You Start
Package Contents
Ÿ TEW-740APBO
Ÿ CD-ROM (User's Guide)
Ÿ Quick Installation Guide
Ÿ Proprietary PoE injector
Ÿ Power adapter (48 V DC, 0.5 A)
Ÿ Mounting Hardware
Ÿ Waterproof RJ-45 plug (network cable is not included)
Ÿ Grounding wire
Minimum Requirements
Ÿ Computer with a network port and web browser
Ÿ A network switch or router with an available network LAN port
Ÿ 2 x RJ-45 network cables (sold separately)
Ÿ Phillips screwdriver (sold separately)
Note:
1. The TEW-740APBO does not support IEEE 802.3at/af. You must use the proprietary Power
over Ethernet injector that is supplied with the TEW-740APBO.
2. Check package contents for waterproof kit (network cable is not included).
Cable Gland Seal Claw
Sealing Nut

TRENDnet TEW-740APBO Specifications

General

5 GHz	No
2.4 GHz	Yes
Modulation	16-QAM, 64-QAM, BPSK, CCK, DQPSK, DSSS, OFDM, QPSK
Networking standards	IEEE 802.11b, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3u
Spread spectrum method	DSSS
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Placement	Pole, Wall
Certification	CE, FCC
International Protection (IP) code	IP67
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	HTTPS, SSID, WDS, WPA-PSK, WPA2, WPA2-PSK, WPA2-RADIUS
Number of SSID supported	8
Service Set Identifier (SSID) features	SSID broadcast on/off
Antenna features	Integrated antenna
Antenna gain level (max)	10 dBi
Input current	0.6 A
Output current	0.5 A
Output voltage	48 V
AC input voltage	100 - 220 V
AC input frequency	50 - 60 Hz
Power consumption (max)	22 W
Operating temperature (T-T)	-30 - 60 °C
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	54 mm
Width	125 mm
Height	218 mm
Weight	424 g
