TRENDnet TEW-740APBO Quick Installation Guide

2
2. Hardware Installation
Phase 1: Overview
Note: The default IP address of the TEW-740APBO is 192.168.10.100. To configure the
TEW-740APBO, your network adapter must have an IP address within the 192.168.10.x subnet
(e.g. 192.168.10.50). Please refer to the Appendix in the User's Guide for more information.
1. Write the MAC address (MAC1) of the two TEW-740APBOs. The MAC address (MAC1) can be
found on the side of the unit. In this example, we will assume the following:
TEW-740APBO #1 MAC Address: 00:11:22:00:00:11
TEW-740APBO #2 MAC Address: 00:11:22:00:11:22

TRENDnet TEW-740APBO Specifications

General

5 GHz	No
2.4 GHz	Yes
Modulation	16-QAM, 64-QAM, BPSK, CCK, DQPSK, DSSS, OFDM, QPSK
Networking standards	IEEE 802.11b, IEEE 802.11d, IEEE 802.11e, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1x, IEEE 802.3u
Spread spectrum method	DSSS
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Placement	Pole, Wall
Certification	CE, FCC
International Protection (IP) code	IP67
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Security algorithms	HTTPS, SSID, WDS, WPA-PSK, WPA2, WPA2-PSK, WPA2-RADIUS
Number of SSID supported	8
Service Set Identifier (SSID) features	SSID broadcast on/off
Antenna features	Integrated antenna
Antenna gain level (max)	10 dBi
Input current	0.6 A
Output current	0.5 A
Output voltage	48 V
AC input voltage	100 - 220 V
AC input frequency	50 - 60 Hz
Power consumption (max)	22 W
Operating temperature (T-T)	-30 - 60 °C
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	54 mm
Width	125 mm
Height	218 mm
Weight	424 g
