Application Diagram
The AC1900 High Power Wireless Dual Band PCIe Adapter can provide wireless AC or
wireless N connectivity to a wireless AC/N network (router/access point) through the
use of an available USB 3.0 port on your computer. The detachable high gain antenna
allows for flexible adjustment to achieve the best possible wireless coverage and
connectivity
