TRENDnet TPL-401E2K - Chapter 6: Specifications

Chapter 6: Specifications
Hardware
Standards
IEEE 1901, HomePlug® AV, IEEE 802.3, IEEE 802.3x, IEEE 802.3u, IEEE
802.3ab
Interface
1 x 10/100/1000Mbps Auto-MDIX RJ-45 Port,
Power Prong
Frequency Band
2 ~ 50 MHz
Modulation
OFDM Symbol Modulation on link synchronization, 1024/256/64/8 -
QAM, QPSK, BPSK, ROBO Carrier
Protocols
TDMA and CSMA/CA
Speed
Powerline: up to 500Mbps**
Ethernet: up to 2 Gbps with Full Duplex mode
Utility OS Compatibility
Windows 7 (32/64-bit), Vista (32/64-bit), XP(32/64-bit)
Nodes
Up to 64 (max.)
Recommended: Up to 16* per powerline network
Overlapping Powerline
Networks
Up to 4 (per electrical system)
Coverage
Up to 300m (984ft.)
Security
128-Bit AES (Advanced Encryption Standard)
LED
Power (PWR), Ethernet Link/Act (ETH)
Powerline (PL) with Connection Quality Indication
 Best (Green)
 Better (Amber)
 Good (Red)
Buttons
Sync, Reset
Dimension (L x W X H)
A: 98 x 72 x 55 mm (3.9 x 2.8 x 2.2 in.) per unit
EU: 98 x 72 x 70 mm (3.9 x 2.8 x 2.8 in.) per unit
Weight
A: Total Weight: 300 g (10.6 oz) / Per Unit Weight: 150 g (5.3 oz)
EU: Total Weight: 310 g (11 oz) / Per Unit Weight: 155 g (5.5 oz)
Power Source
A: 100~230V AC, 50~60Hz
EU: 220~240V/ 5A AC, 50Hz
Consumption
Active mode: 4.69 Watts (max. per unit)
Standby mode: 0.85 Watts (max. per unit)
Temperature
Operating: 0° ~ 40°C (32° ~ 104°F)
Storage: -20° ~ 70°C (-4° ~ 158°F)
Humidity
Max. 90% (non-condensing)
Certifications
CE, FCC
* Maximum of 16 adapters (nodes) recommended for streaming video across your network. Additional adapters may
decrease performance.
** 500Mbps is the maximum theoretical Powerline data rate. Actual throughput will vary depending on environment.
*** Networked Powerline devices need to be plugged into power outlets that are on the same electrical system.
